1. Electrical switchboards 2. HVAC systems 3. Electrical circuit faults detection 4. Installation or maintenance of electronics/factory equipment 5. Electronics component development, circuit board design 6. Users who need to distinguish between neutral/live wire frequently
DC Voltage 600mV/6V/60V/600V/1000V ±(0.5%+2)
AC Voltage 6V/60V/600V/750V ±(0.8%+3)
ACV Frequency 10Hz～10kHz ±（0.1%+5)
DC Current 60uA//600uA/6mA/60mA/600mA/20A ±(0.8%+8)
AC Current 60uA/600uA/6mA/60mA/600mA/20A ±(1%+12)
Resistance 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ ±(0.8%+3)
Capacitor 6.000nF/60.00nF/600.0nF/6.000μF/60.00μF/600.0μF/6.000mF/60.00mF/100.0mF ±(3%+10)
Frequency 9.999Hz～9.999MHz ±(1.0%+5)
Display Count 6000
Manual Range √
NCV √
hFE √
Diode Test √
Continuity Test √
Live √
True RMS √
Fuse blowing alarm √
Acousto-optic indication(NCV/continuity) √
High voltage false detection 1000Vrms √
Current (AC/DC) mode memory √
Over-current alarm ≥20A √
Low Battery Indication ≤2.5V √
Data Hold √
REL √
Max/Min V 、A √
Auto Power Off 15Min √
Back light 30s √
Safety CAT Ⅱ 1000V/CAT III 600V
Warranty: 1 Year
