OWON SDS-6062 60 MHz Digital Storage Oscilloscope

Features
Type of Product : Digital Storage Oscilloscope
Sub Type : Deep Memory Type
Bandwidth : 60 MHz
Bandwidth Limit : 60 MHz
Sample Rate : 500/MS/s

Max. Input voltage : 400 V (peak)
Real-time sample rate : 10 Sa/s to 500 MSa/s real time
Time base : 5 ns/Div. to 5 s/Div. (Steps 1 – 2 – 5)
Memory: 10 Mpts per channel

Analog digital converter (A/D) With the resolution of 8 bits, make sampling on both channels synchronously.
Sensitivity range (V/div) 2 mV/Div to 10 V/Div.
Displacement range

Warranty: As per Owon’s policy.

The new digital storage oscilloscope SDS6062 offers a reliable measurement technology.
The colorful 8″” (20.3 cm) TFT LCD panel with the resolution of 800 × 600 allows an excellent readability of the wave, especially in regards to high data volume or many waves covered reciprocally.
