| Measurement Range | Resolution | Accruacy | ||
| DC Voltage | 6.000V / 600.0V / 60.00V | 0.01mV | ±(0.5%+2-dig) | |
| 1000V | 1V | ±(0.8%+2-dig) | ||
| AC Voltage | 6.000V / 60.00V / 600.0V | 0.1mV | ±(0.8%+3-dig) | |
| 750V | 1V | ±(1%+3-dig) | ||
| μA | 60.00uA / 600.0μA | 0.01μA | ||
| DC Current | mA | 60.00mA / 600.0mA | 0.01mA | ±(0.8%+2-dig) |
| A | 10.00A | 0.01A | ±(1.2%+3-dig) | |
| μA | 60.00uA / 600.0μA | 0.01μA | ||
| AC Current | mA | 60.00mA / 600.0mA | 0.01mA | ±(1%+3-dig) |
| A | 10.00A | 0.01A | ±(1.5%+3-dig) | |
| Resistance | 600.0Ω / 6.000kΩ / 60.00kΩ / 600.0kΩ / 6.000MΩ | 0.1Ω | ±(0.8%+2-dig) | |
| 60.00MΩ | 0.01MΩ | ±(2%+3-dig | ||
| Capacitance | 60.00nF / 600.0nF / 6.000μF / 60.00μF | 0.01nF | ±(2.5%+3-dig) | |
| 600.0μF / 6.000mF / 60.00mF | 0.1μF | ±(3%+5-dig) | ||
| Frequency | 9.999Hz / 99.99Hz / 999.9Hz / 9.999kHz / 99.99kHz
/ 99.9kHz / 9.999MHz |
0.001Hz | ±(0.8%+2-dig) | |
| Duty Ratio | 0.1% – 99.9% (typical value: Vrms=1V, f=1kHz) | 0.10% | ±(1.2%+3-dig) | |
| 0.1% – 9 9.9% (≥1kHz) | ±(2.5%+3-dig) | |||
| Temperature | (-50℃) – (+400℃) | 1℃ | ±(2.5%+3-dig) | |
| (-58°F) – (+752°F) | 1℉ | ±(4.5%+5-dig) | ||
| Display | 5999 | |||
| Frequency | (40 – 1000) Hz | |||
| Shift Rate | 3 times/s |
Warranty: 1 Year
