HTC Instruments DC 3002-II DC 2A Linear Dual Power Supply

– Line Regulation : CV ≤0.01% + 3mV ; * CC ≤0.2 % + 3 mA
– Load Regulation : CV ≤0.01% + 3mV ; * CC ≤0.2 % + 3 mA
– Ripple and Noise : CV ≤1mV rms ; * CV ≤3 mA rms
– Protection : Constant current and Short-circuit protection
– Tracking Error : ≤0.5% +10 mV
– Indication Accuracy : ≤0.5% +1digit
– Input Voltage : 220 V AC ± 10%, 50hz ± 2Hz
– O/P Voltage: 0~30V
– O/p Current: 0~2A
– FIXED O/P: 5V,2A
– Dimensions :240 X 150 X 270mm

– Model: DC 3002-II
– Standard Accessories : Power Cord, Manual, Test Lead

A regulated power supply is an embedded circuit; it converts unregulated AC into a constant DC
